Rock compression testing machine

  • It's used to test the mechanical properties of rocks

SHARE:

  • Main Function and Usage


    • The rock compression testing machine is mainly used to test the mechanical properties of rocks, such as compressive strength, shear strength, elastic modulus, Poisson ratio and so on. The machine is equipped with a special extensometer for rock, which can simultaneously measure the transverse and longitudinal deformation of the sample. According to different test requirements, the corresponding accessories can be configured.


    Main Specifications and Techinical Parameter


    Maximum test force2000kN
    Test force measurement range2%-100%FS
    The relative error of the test force indication   value≤±1%
    Upper and lower pressure plate spacing360mm
    Piston stroke 80mm
    Column spacing260mm
    Pressure plate size260×300mm
    Column diameter 67mm
    Piston diameter310mm
    Main machine dimensions635×500×1430mm


  •

    20191029151144322.jpg@!w1200



    20191025121423286.jpg@!w1200
